Archer 4

FEATURES

•  Reliable mobile operating system

  The Archer 4 runs on the Android 14 operating system and will support upgrades through Android 18, providing security and compatibility for years to come. The Archer 4 is also Google Mobile Services certified to provide users with a reliable platform for running popular data collection software.

•  Connectivity

  The Archer 4 is a versatile communication device allowing you to stay connected to your network, the Cloud, or other devices. The processor chipset on every unit supports 5G cellular voice and data connectivity, Wi-Fi 6 compatibility, Class 1 Bluetooth 5.2 functionality, and provides dual-band GNSS location data.

•  All-day usability

  From its ergonomic enclosure to its sunlight-readable display, and down to its all-day battery life, the Archer 4 is built for long workdays wherever the job takes you.

•  Expandable

  To meet the needs of any job, the capabilities of the Archer 4 can be enhanced with either our modular barcode scanner or sub-meter GNSS expansion pods.

•  Battery

  A choice of battery size means you can pack your Archer 4 with more power for a long day, or pop in the smaller battery for a more compact carrying setup. Hot-swapping batteries allows you to switch out a new battery without powering down the device and interrupting your workflow.

•  Built Juniper Rugged™

  At Juniper, we put our hardware through the wringer. Even after we meet IP68 and MIL-STD-810H standards for water, dust/debris and shock, we continue to test-to-fail so we know just how far users can push our devices. Rest assured rain, extreme temperatures, debris, and accidental drops or dunks won’t stop a productive workday with the Archer 4.

ARCHER 4 SPECIFICATIONS

• Qualcomm® QCM4490 octa-core up to 2.4 GHz

• Operating system: Android™ 14
• GMS (Google Mobile Services) certified using EDLA
• Upgradeable through Android 18

• Memory (RAM): 8 GB
• Internal Storage (ROM): 128 GB
• SD Card Storage up to 512 GB

• 5G with 4G LTE fallback, Dual Nano SIM card slots
• Cellular: LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B20/B25/B26/B28a/B66/B71, LTE-TDD: B38/B40/B41, 5G: N1, N2, N5, N41, N66, N71, N77, N78
• Wi-Fi®: 6E 802.11 2.4/5 GHZ a/b/g/n/ac, 802.11 ax
• Bluetooth® 5.2
• Dual-band GPS, GLONASS, Beidou, Galileo, QZSS
• NFC
• OTG
• USB Type-C (5Gbps, 5V power delivery)

• Ingress protection: IP68 waterproof & dustproof
• Operating Temperature: -4 F to 140 F (-20 C to 60 C)
• Meets MIL-STD-810H test procedures: Method 500.6 Low Pressure, Method 501.7 High Temperature, 502.7 Low Temperature, 503.7 Temperature Shock, 506.6 Rain, 507.6 Humidity, 510.7 Sand and Dust, 512.6 Immersion, 514.8 Vibration, 516.8 Shock

• Weight: .72–.87 lbs (325–395 g) depending on battery and expansion configuration
• Dimensions with 4500 mAh battery: 174 x 85 x 15 mm
• Dimensions with 8300 mAh battery: 174 x 85 x 22 mm
• 2 user programmable buttons

• 540 Nits typical
• Screen size (diagonal): 6.26”
• Screen resolution: 2280 x 1080 FHD+
• Capacitive multi-touch interface for wet conditions
• Chemically-strengthened Gorilla® Glass 5
• Optimized for extreme environments including wet touch

• Front: 16 MP
• Rear: 48 MP with LED illumination

• Optional 1D/2D barcode add-on
• Sub-meter GNSS receiver (RTK capable)

• Removable Li-ion battery
• Battery size: 4500 mAh (standard) or 8300 mAh (optional upgrade)
• Internal 300 mAh battery allows for hot-swapping

• IC/FCC/CE
• UKCA
• ROHS, REACH, REACH Restriction Article, EU POP, WEEE
• California Prop 65
• TSCA
• Bluetooth SIG
• RCM
• Japan Radio (TELEC, JATE)
• Brazil ANATEL
• SCIP
• Canada Prohibition
• ERP, CEC, DOE
• PTCRB
• Global Certification Forum (GCF)
• AT&T Network Approved

• Available upon request
